RF Series Steel Nipple with Hose Barb
Note: This product is no longer available - please refer to the “Recommended Products” section of this page for alternative products, or contact us for further assistance.
Note: This product is no longer available - please refer to the “Recommended Products” section of this page for alternative products, or contact us for further assistance.
RF Series Nipples (pneumatic, air) up to 300 psi, connect with RF Series Couplers and are interchangeable with common High Flow European couplings. Parker's rapid flow couplings are push-to-connect, single shut off quick couplings.
1/4' RF Series functionally interchanges with Rectus 25 and CEJN 320. 3/8' RF Series functionally interchanges with Rectus 27 and CEJN 410.
Flow rates on the 1/4' size are greater than many 3/8' size nipples and the 3/8' size flow rates are greater than many 1/2' size nipples. The increased flow results in greater tool efficiency and decreased air costs.
High flow nipples are also used on breathing air lines and respirator equipment used in paint booths, chemical laboratories and similar environments.
Technical Characteristics:
• Sizes: 1/4”, 3/8”
• Material: Steel
• Port Ends: Female NPTF, Male NPTF, Standard Hose Barb, Push-Lok Hose Barb
Markets:
• Industrial
• Construction
• Automotive service and repair
• Factory automation
• Environmental health and safety
Features/Benefits:
• High flow performance. Up to 2-1/2 times larger flow area than standard industrial interchange nipples, resulting in greater tool efficiency and decreased air costs.
• Case hardened steel for durability
• Interchangeable with high flow European profile nipples
Applications:
• Safety equipment, respirators
• Air compressors
• Pneumatic air tools and hoses
• Water lines
• Grease guns
• Cleaning equipment
• Paint applicators
• Drop-down air lines
• Blow guns
1/4' RF Series functionally interchanges with Rectus 25 and CEJN 320. 3/8' RF Series functionally interchanges with Rectus 27 and CEJN 410.
Flow rates on the 1/4' size are greater than many 3/8' size nipples and the 3/8' size flow rates are greater than many 1/2' size nipples. The increased flow results in greater tool efficiency and decreased air costs.
High flow nipples are also used on breathing air lines and respirator equipment used in paint booths, chemical laboratories and similar environments.
Technical Characteristics:
• Sizes: 1/4”, 3/8”
• Material: Steel
• Port Ends: Female NPTF, Male NPTF, Standard Hose Barb, Push-Lok Hose Barb
Markets:
• Industrial
• Construction
• Automotive service and repair
• Factory automation
• Environmental health and safety
Features/Benefits:
• High flow performance. Up to 2-1/2 times larger flow area than standard industrial interchange nipples, resulting in greater tool efficiency and decreased air costs.
• Case hardened steel for durability
• Interchangeable with high flow European profile nipples
Applications:
• Safety equipment, respirators
• Air compressors
• Pneumatic air tools and hoses
• Water lines
• Grease guns
• Cleaning equipment
• Paint applicators
• Drop-down air lines
• Blow guns
| Division | Quick Coupling Division |
| Media | Compressed Air |
| Application | Pneumatic |
| Maximum Operating Temperature | 250 °F |
| Maximum Operating Pressure | 300 psi |
| Body Material | Steel |
| Plating Type | Zinc with Clear Trivalent Chromate |
| Coupling Half | Nipple |
| Specifications Met | Interchanges with Rectus 27 and CEJN 410 |
| Minimum Operating Temperature | -40 °F |
| Media | Low Pressure Fluids |
| Valve Type | Unvalved |
| Part Number |
|---|
| RF-374-6HB |
